Corner Spacer


spacer
Home > Products > Transmissions > Transmission Pumps


Front Pumps


Our standard transmission front pumps are fully blueprinted and assembled with high performance bushings, seals, and high flow lube circuits.

Super Pumps
The Super Pump and stator are CNC-machined from billet aluminum for precision and durability. Re-engineered lubrication circuits allow for increased flow volume in all critical areas. In fact, the pump thickness has been increased to improve oil pressure and volume at low RPM resulting in a cool running transmission and converter.

Superior pressure
Improved transbrake hold
Prevents stator tube spin out

Powerglide Super Pumps
Applications
Part Number
Price
POWERGLIDE - SUPER PUMP
205032
$629.00
POWERGLIDE - SUPER PUMP - RINGS INSTALLED FOR 207148, 207149 & 207159AV SUPER SHAFTS ONLY
205038
$649.00
POWERGLIDE - SUPER PUMP - SG4
205058
$695.00
    KIT - SUPER PUMP - PUMP BODY OEM SIZE - NEW ALUMINUM SUPER PUMP GEAR SIDE WITH SNAP RING,
    SEAL, BUSHING, COATED GEAR SET AND WEAR PLATES, READY TO BOLT ON
205033K1
$299.00
    KIT - SUPER PUMP - PUMP BODY SG4 SIZE - NEW ALUMINUM SUPER PUMP GEAR SIDE WITH SNAP RING,
    SEAL, BUSHING, COATED GEAR SET AND WEAR PLATES, READY TO BOLT ON
205033K2
$299.00


Powerglide Pump Sealing Components
Applications
Part Number
Price
SUPER PUMP O-RING KIT - SEALS STATOR TUBE TO BODY (SET OF 5)
205036
$12.00
TEFLON RINGS FOR PUMP TO DRUM (SET OF 2)
205025
$21.00
LARGE O-RING , FRONT PUMP TO CASE
205370
$4.61
OIL RINGS (SET OF 4 - 2 PUMP, 2 INPUT SHAFT) - USE FOR A MAX OF 200 PSI!
205020
$29.95


Powerglide Pumps
Applications
Part Number
Price
PG - STANDARD - HEAT TREATED STATOR SUPPORT
205031
$389.00
PG - PUMP ASSY FOR RINGLESS 19 SPLINE SUPER SHAFT (205232), HEAT TREATED STATOR SUPPORT
205052
$389.00


Powerglide Pump Gaskets
Use these gaskets as shims when setting end play. They eliminate the GM “drain slit” at the bottom bolt hole.

Part Number
Price
PUMP GASKET SET - INCLUDES (6) .015”, (2) .030” AND (2) .045”
205380
$23.10



TH400 Pumps
Applications
Part #
Price
TH400 - FRONT PUMP W/COOLER
405020
$329.00
TH400 - FRONT PUMP W/COOLER AND HEAT TREATED STATOR TUBE
405025
$395.00


TH400 Super Pump
ATI's Turbo 400 Super Pump is designed to prevent tube damage and increase fluid flow for better cooling. Starting with a new permanent-mold Aluminum casting, the finished pump features a 3 piece design with a bolt-in, one-piece, heat treated alloy steel stator tube for improved fluid routing over the pressed in OEM or aftermarket tubes. Micro-finished coated gears and ATI’s exclusive hardened steel wear plates are standard equipment. At just 12 lbs, the ATI pump is 5 lbs less than an OEM unit. The gear side comes with 6 bolt holes drilled and 2 left spotted for easy addition by the builder as needed for 8 bolt applications. Gear side will mate with all current steel stator halves. The OEM fluid passages and depths were retained as well as the pressure regulator. Adjustable pressure regulator is also available. Fits OEM sized input shafts with larger sizes available for high HP use.

Application
Part No.
Price
TH400 - SUPER PUMP - OEM SHAFT - 180+ PSI SPRING 400
405038
$695.00
    Kit - Super Pump body - OEM shaft with gears and wear plates
405033K1
$325.00
    Kit - Super Pump Stator half - OEM regulator and beefy spring,
    bolts, washers
405133K
$405.00
    Stator tube / Plate assembly only - OEM size T400
405133
$395.00
TH400 - SUPER PUMP - BIG SHAFT - ADJUSTABLE PRESSURE     REGULATOR
405058
$739.00
    Kit - Pump body - T400 Big shaft with gears and wear plates
405033K2
$325.00
    Kit - Stator half with adjustable regulator
405153K
$450.00
    Kit - Stator tube plate assembly - only big shaft
405153
$375.00
ADJUSTABLE REGULATOR KIT - T400 SUPER PUMP
ELIMINATES OEM BOOST VALVE - 185 - 300 PSI
405183
$84.95
SPACER - T400 PRESSURE REGULATOR BOOST
    PUMP 210+ PSI
405131
$7.49



TH400 Pump Gaskets
ATI's T400 Front Pump Gasket Set (Part #405380) includes Ten gaskets in three thicknesses to help you set the correct end play without stacking shims or going to the lathe. Six OEM size 0.015”, two 0.030” and two 0.045” thick gaskets come in the kit. As every builder knows correct front end play is critical to proper function and long transmission life.



Applications
Part #
Price
TH400 PUMP GASKET SET - 10 GASKETS - (6) .015", (2) .030", (2) .045"
405380
$26.95
TH400 PUMP GASKET - .015" OEM THICKNESS
405380-15
$4.49
TH400 PUMP GASKET - .030"
405380-30
$4.49
TH400 PUMP GASKET - .045"
405380-45
$4.69


TH350 Pumps
Applications
Part #
Price
TH350 - NO LOCK UP W/COOLER
355010
$329
TH350 - NO LOCK UP, NO COOLER
355020
$339

Chrysler TF727 & TF904 Pump Components
Applications
Part #
Price
TF727 - SEAL KIT FOR FRONT PUMP
725100
$17.46
FRONT PUMP STATOR RING (1962-1970)
725001
$6.36
FRONT PUMP STATOR RING (1971 & UP)
725021
$7.52
FRONT PUMP SEAL, TF-727
725130
$8.87
FRONT PUMP SEAL, TF-904
905130
$9.22
O-RING - FRONT PUMP TO CASE, TF-727
725110
$4.67
O-RING - FRONT PUMP TO CASE, TF-904
905110
$4.67
GASKET - FRONT PUMP TO CASE, TF-727
725120
$4.67
GASKET - FRONT PUMP TO CASE, TF-904
905120
$3.85
GEAR KIT - FRONT PUMP NON-LOCK-UP, TF-727
725170
$42.56



C4 & C6 Pump Components
Applications
Part #
Price
C-4 - FRONT PUMP KIT - SEAL, BUSHING, GASKET & O-RINGS
645100
$16.99
C-4 / C-6 - SEAL FOR FRONT PUMPS
645130
$9.92
